BP SX10 Solar Panel / Multimount Frame

With 36 multicrystalline cells in series, the SX 10 10 watt solar panel charges 12V batteries efficiently in virtually any climate. Typical commercial applications of this module, which generates nominal maximum power of 10 watts, includes remote telemetry, instrumentation systems, security sensors, and signals. The versatile Multimount frame of the SX10Mprovides great flexibility in mounting. Oriented parallel to the edge and back of the module, its dual channels accept the heads of 8mm or 5/16" hex bolts, allowing the module to be mounted from the side or back. Bolts may be located anywhere along the channels, a configuration which avoids nuts from turning during tightening and allows installation with just one wrench. Output of the SX 10M is via a 4.6m (15 foot) PVC jacketed 1mm2 (AWG 18-2) cable which terminates in a low-profile junction box on the module back. Epoxy-potted in the box, module electrical connections are sealed against corrosion and effectively strain-relieved. The SX10M is intended for single-module applications.
