Click for reviews
| Model Number | PVP2500 |
| AC Nominal Power (W) | 2500.0 |
| Peak Efficiency | 0.945 |
| CEC Weighted Efficiency | 0.920 |
| Weight (lbs) | 65.0 |
| Height (in) | 30.4 |
| Width (in) | 15.6 |
| Depth (in) | 8.3 |
PV Powered PVP2500 Inverters
- Integrated AC and DC PV Disconnect
- CEC Weighted Efficiency: 94.5%
- Easy Installation through reduced interconnections and optimally placed knockouts
- Factory integrated inverter and PV System Disconnect eliminates the need for extra equipment
- Field-configurable inverter grounding schema with simple jumper selection
- RMA program includes $400 purchase credit or $150 service reimbursement
- Endurance tested 20 year operating life
- Lowest part counts and fewest interconnects eliminate common failure points
- Field-proven technology with thousands of units installed nationwide
- Direct-to-wall surface enclosure design allows for easy access and installation
- Single AC/DC switch visible and lockable in the OFF position
- NEC compliant internal raceway enables flush side-by-side mounting
