SolarEdge Energy Hub SE10000H-US Single Phase Inverter with Prism Technology


SolarEdge Model Number	SE10000H-US
Rated AC Power On Grid	10,000W
Rated AC Power Backup	10,000W
Nominal Output Voltage	240V
Max. DC Power Input	20,000W
Max DC Input Voltage	480V
Nominal DC Input Voltage	380V
Max. Input Current	27.0A
Inverter Efficiency	99.2%
CEC Weighted Efficiency	99%
Nighttime Power Consumption	< 2.5W

SolarEdge HD Wave inverter home solar system

DIY SolarEdge Solar Systems

SolarEdge Energy Hub SE10000H-US Single Phase Inverter with Prism Technology

Name: SolarEdge Energy Hub SE10000H-US Single Phase Inverter with Prism Technology
SKU: SE10000H-US-HD-Wave-Prism-Inverter

SKU SE10000H-US-HD-Wave-Prism-Inverter

SolarEdge SE10000H-US Energy Hub Inverter with Prism Technology

In June 2020, SolarEdge released the newest edition of their product line, the Energy Hub Inverter with Prism Technology. The Energy Hub is an energy-backup inverter that functions similar to a conventional string inverter but is battery-compatible.

Solar Edge inverter w/ Prism Technology possibilities

This means that the user can save unused solar energy during the day for later (i.e., the nighttime). Without energy storage, solar energy goes to waste if it’s unused at the time of production - the energy either gets sent back to the grid where the user may get little to no credits.

Designed for use with SolarEdge Power Optimizers for the most efficient grid-tie inverter solar system available. We carry the latest SE10000H-US UL1741, UL1699B, certified inverters with ground-fault isolation detection and interruption compliance.

The SolarEdge HD Wave inverters use a unique power conversion technology that is based on a distributed switching and powerful DSP processing platform. HD-Wave technology is able to synthesize a clean sine wave that leads to a dramatic reduction in the magnetics and heavy cooling elements.

This small and lightweight inverter enables simplified shipping, storing and one-person installation. The record-breaking efficiency allows more energy production for residential grid-tie solar systems.

SE10000H-US w/ Prism Technology Key Features

The SolarEdge SE10000H-US is lightweight enough to be installed by one person.

Record-breaking 99% weighted efficiency with 200% DC oversizing!
Multi-inverter, scalable storage solution
Small, lightweight, and simple to install
Modular design, future ready with optional upgrades available
Integrated arc fault protection and rapid shutdown for NEC 2014, NEC 2017 and NEC 2020, per article 690.11 and 690.12
Enhanced battery power up to 10kW
Embedded revenue grade production data, ANSI C12.20 Class 0.5

SolarEdge SE10000H-US Add-On Possibilities

The SolarEdge Energy Hub inverter with Prism technology enables future homeowner needs through easy connection to a growing ecosystem of products.

Battery Backups

EV Charging

Consumption

Generator Compatible

Connected Add-Ons

Solar Electric Supply has been helping solar contractors and handy DIY homeowners for over 20 years.

Attachments Details

SolarEdge SE10000H-US Single Phase Energy Hub Inverter W/ Prism Technology Review

Power Everyday Life with The SolarEdge Energy Hub

The award-winning Energy Hub inverter provides an efficient, flexible solar & storage platform, offering
connection to powerful home backup, EV charging, real-time monitoring and a growing line of SolarEdge
Smart Energy Products.

Record Setting Efficiency
Energy Hub helps maximize
solar consumption and savings
thanks to its outstanding
efficiency

A System That Grows with You
Satisfy growing needs with
connection to multiple inverters
and an expanding line of
SolarEdge Smart Energy Products

Stay On When the Grid Is Off
Energy Hub easily connects
to multiple batteries and
a third party generator
for extended power.

SolarEdge W/ Prism Technology Highlights:

Solar inverters specifically designed to work with SolarEdge power optimizers
90.8% overall system efficiency
Increase energy independence from the grid
Simpler installation process while avoiding main panel upgrades, generation panels, and utility delays
For greater power and capacity, add more inverters and batteries
Internet connection through Ethernet or wireless connectivity (using Wi-Fi, ZigBee or GSM Plug-ins)
Generator compatible
IP65 / NEMA 3R – suitable for outdoor and indoor installations
Integrated arc fault protection and rapid shutdown for NEC 2014, NEC 2017 and NEC 2020, per article 690.11 and 690.12
Embedded revenue grade production data, ANSI C12.20 Class 0.50
All inverters are UL1741 SA certified, for CPUC Rule 21 grid compliance

A New Era for PV Inverters with HD-Wave Technology: <30 lbs, 99% Efficiency, Integrated Auto Rapid Shutdown

SolarEdge's single phase inverter with HD-Wave technology, winner of the prestigious 2016 Intersolar award and the renowned 2018 Edison Award, breaks the mold of traditional inverters. Using a novel power conversion technology that is based on a distributed switching and powerful DSP processing, the single phase inverter is able to synthesize a clean sine wave that leads to a dramatic reduction in the magnetics and heavy cooling elements. This small and lightweight inverter enables simplified shipping and storing and one-person installation. The record-breaking 99% efficiency allows more energy production for an improved ROI.

Additional Highlights:

Small and lightweight
99% CEC weighted efficiency
One storage solution w/ ability to backup the entire home
Modular design, future ready with optional upgrades to:

DC-coupled storage for full or partial home backup
Built-in consumption monitoring
Direct connection to the SolarEdge smart EV charger

Longer strings (up to 5,700W per string)
High reliability due to lower heat dissipation

The SolarEdge single phase inverter combines sophisticated digital control technology with efficient power conversion architecture to achieve superior solar power harvesting and best-in-class reliability.

A proprietary data monitoring receiver has been integrated into the single phase inverter and aggregates the power optimizer performance data from each PV module. This data can be transmitted to the web and accessed via the SolarEdge monitoring platform for performance analysis, fault detection and troubleshooting of PV systems.

The single phase inverter comes with a built-in DC safety switch, integrated rapid shutdown and a standard 12-year warranty.

Highest Efficiency In Sun & Partially Shaded Conditions

The HD Wave SE10000H-US inverter is part of SolarEdge’s HD Wave single-phase inverter series. These are designed to provide higher-power systems at a lower cost than multiple small convection cooled inverters or traditional string inverters. Solar Optimizers used in SolarEdge inverter systems solve many problems that inherently exist with traditional string inverters:

Traditional Inverter

MPPT per entire string - all modules receive the same current, regardless of their individual MPP
Weak modules reduce the performance of all modules in the string or are bypassed altogether
Power losses due to module mismatch
